Belt Conveyors

Our range of steel and aluminium belt conveyors starts with our precision M1950 Medium Duty conveyor at 0.9kw, up to our 1.5kv MHD-CU Heavy Duty conveyor. Due to our wide range of belt conveyors we are able to provide a solution for many applications. The MHD-CU Heavy duty units can also be used as an Interfloor conveyor which offers a simple and reliable method for transferring totes or cardboard boxes between floor levels.

M1950 Belt Conveyor

MHD-CU Belt Conveyor

Load Up to 15kg per meter Up to 25kg per meter
Belt Conveyor Widths 100mm to 500mm 350mm to 850mm
Standard Speeds (meter/minute)** 3 / 5 / 10 / 14 / 18 12 / 15 / 19 / 24 / 30
Framework ‘M’ 40x40mm aluminium extrusion side frame with stainless steel top plate. 'MT’ 40x80mm aluminium extrusion side frame which encloses the belt. Stainless steel top plate. 175.5mm x 40mm powder coated steel or aluminium ‘C’ Section, having return folds for to retention of the facia.178mm x 32mm x 2.5mm fully jig-welded ‘Z’ section.
Key Features Compact size suitable for small to medium sized products.Small end rollers for good product transfer. Robust framework for heavy products and long distances. Available for incline, decline and horizontal travel.

** Final belt conveyor speeds will depend on the type of drive selected. Special speeds are also available.
